Hsd Transfer Pump

Get a Price/Quote

Hsd Transfer Pump Specification

Features
Heavy Duty, Durable, Efficient

Flow Rate
10 m/hr

Caliber
50 mm

Discharge Pressure
3.5 Bar

Fuel Tank Capacity
External Source

Voltage
415 V

Noise Level
Low

Speed
2900 RPM

Max Suction
7 m

Head Size
35 m

Theory
Centrifugal Pump

Inlet/Outlet
2 inch / 2 inch

Working Temperature
-10 to +60

Control System
Manual

Frequency
50 Hz

Mounting Type
Horizontal

Material
Cast Iron

Structure
Single Stage

Power
2.2 kW

Standard
IS:8472

Fuel Type
Diesel

Pressure
3.5 Bar

Usage
HSD Transfer, Fuel Transfer

Application
Industrial/Fuel Station

Suction Type
Positive Displacement

Seals Type
Mechanical Seal

Priming
Self Priming

Pump Type
Transfer Pump

Capacity
10 m/hr

Painting
Anti-Corrosive Paint

Protection Class
IP55

Service
Continuous Duty

Shaft Material
Stainless Steel

Cooling Method
Air Cooled

Impeller Type
Close Impeller

About Hsd Transfer Pump

We are an established manufacturer, exporter and supplier of Hsd Transfer Pump. This pump has a vital role in removing deposition of solid and fibrous materials in conventional pumps. This specific pump consists of important parts like heat treated gears and axles. The distinctive features of our Hsd Transfer Pump include its compact design, well built formation and long lasting nature. This high speed diesel transfer pump acts as a booster pump in oil delivery system. Apart from that, the offered pump is also utilized for pressurization and injection in fuel supply system.

Features

Easy to operation, easy to install
Robust construction
Quick installation
Lower maintenance cost

Performance and Reliability

Engineered for industrial-grade performance, this transfer pump maintains consistent flow even under challenging conditions. With a centrifugal design, continuous duty rating, and robust 2.2 kW motor, it delivers efficient fuel handling for high-volume operations. Users benefit from reliable, maintenance-friendly operation, bolstered by self-priming capability and mechanical seals for minimal leakage.

Durability and Safety

Built with premium materials like cast iron and stainless steel, this pump is protected by anti-corrosive paint to withstand tough working environments. The IP55 protection class and air-cooled system enhance safety and longevity. Its quiet performance and horizontal mounting add further versatility, making it ideal for fuel stations and industrial applications alike.

FAQs of Hsd Transfer Pump:

Q: How does the self-priming feature improve the operation of this transfer pump?

A: Self-priming capability enables the HSD Transfer Pump to evacuate air from the suction line and begin pumping automatically, reducing the need for manual priming. This streamlines start-up processes, particularly valuable in applications like diesel and fuel transfer where operational efficiency is essential.

Q: What benefits does the close impeller design offer for diesel transfer tasks?

A: A close impeller improves hydraulic efficiency and minimizes energy loss, ensuring consistent flow and pressure while reducing the risk of clogging. This design is ideal for clean fluids like diesel, supporting continuous and heavy-duty pumping operations.

Q: When is this pump suitable for use regarding temperature conditions?

A: The pump operates efficiently within a temperature range of -10C to +60C, allowing it to function reliably in various environmental conditions, whether installed outdoors at a fuel station or within industrial facilities.

Q: Where can this HSD Transfer Pump be installed for optimal performance?

A: It is designed for horizontal mounting and can be utilized at industrial sites or fuel stations requiring efficient fuel or diesel transfer. Its rugged build and compact structure make it suitable for restricted spaces with external fuel tanks.

Q: What is the recommended process for operating and maintaining this pump?

A: To operate, ensure the inlet and outlet connections are secure, and fuel is supplied from an external tank. The manual control system allows for straightforward use. Regularly inspect the mechanical seal, check anti-corrosive coatings, and maintain the air-cooled motor for optimal, long-term performance.

Q: How does the IP55 protection class contribute to the pumps durability?

A: The IP55 rating indicates resistance to dust ingress and water jets, safeguarding the pumps internals from harsh industrial environments and extending its operational lifespan.

Q: What advantages does stainless steel shaft construction provide?

A: The stainless steel shaft offers superior resistance to corrosion, particularly when handling diesel fuels, and enhances durability under continuous load, contributing to maintenance-free, long-lasting service.
